Application Area

UPS power supply OBC car charger Charging station Portable DC charger PV Inverter Server power Charger Inverter welding machine Stage light power supply Outdoor power supply LED plant lighting

Charger

Application description

The charger adopts high-frequency power technology and utilizes advanced intelligent dynamic adjustment charging technology. It adopts a three-stage intelligent charging method of constant current/constant voltage/small constant current, and is widely used for battery charging of electric pallet trucks, electric forklifts, electric handling vehicles, electric lifting vehicles, electric tour buses, golf carts, electric scooters, agricultural drones, crop protection drones, firefighting drones and other equipment.

Classic application topology diagram

Recommended application selection

SJ MOSFET

Model
VDS（V）
Rdson Max（mΩ）
Encapsulation

HXMH60M105PHXMH60M99EPHXMH60M70EPHXMH60M40EPHXMH60M28EPHXMH60M75PHXMH60M30P
600600600600600600600
105997040287530
TO-247ABTO-247ABTO-247ABTO-247ABTO-247ABTO-247ABTO-247AB

FRD DIODES

Model
VRRM(V)
IF(A)
Trr（ns）
VF(V)
Encapsulation

SFP3006ASFP3004SFP3006SFP6003SFP6004SFP6006
600400600300400600
303030606060
503535505050
1.551.51.71.31.41.6
TO-247AC-ATO-247ABTO-247ABTO-247ABTO-247ABTO-247AB

SKY DIODES

Model
VRRM(V)
IF(A)
VF(V)
Encapsulation

MBR30200FCTMBR30200PTMBR60150CDMBR60150PTMBR80H150PTMBR100H150PTMBR80H200PTMBR100H200PT
200200150150150150200200
303060608010080100
0.90.90.850.880.930.920.930.9
ITO-220ABTO-247ABTO-263-2LTO-247ABTO-247ABTO-247ABTO-247ABTO-247AB

SIC DIODES

Model
VRRM(V)
IF(A)
VF(V)
Encapsulation

ECR1065AECR1665AECR2065AECR3065AECR4065AECRP2065AECRP3065AECRP4065AECR2065PTECR3265PTECR4065PT
650650650650650650650650650650650
1016203040203040203240
1.61.61.61.61.61.61.61.61.61.61.6
TO-220AC-ATO-220AC-ATO-220AC-ATO-220AC-ATO-220AC-ATO-247AC-ATO-247AC-ATO-247AC-ATO-247ABTO-247ABTO-247AB
